16mm heatguard triplewall polycarbonate cut to size
£27.00 Including VAT sq m
<strong>Cell structure: tunnel-shaped
Thickness: 16 mm or 5/8 inch
Weight: 2700 grams/m² (0.55 psf)
16mm heatguard triplewall polycarbonate cut to size
Upgrade your roof with the 16 mm Heatguard Grey Polycarbonate Sheet. This sheet is strong and keeps your space cool. It also helps save energy by controlling heat. You can use it on carports, greenhouses, and more.
These roofing panels have special features that make them exceptional. They reduce heat buildup by 50%, making your area more comfortable. They are also 200 times stronger than glass, so they won’t break easily. Plus, they resist UV rays, which helps them last longer.
For example, if you live in a sunny area, these sheets can help keep your home cool.
The 16 mm Heatguard sheets have a fire-resistant rating, ensuring safety in case of fire. They are lightweight, making them easy to install. The triple-wall design improves insulation, which helps save on energy bills. They also reduce condensation, making your space brighter.
If you want to build a greenhouse, these sheets would be perfect.
You get a 10-year warranty with the product, so you know it will last. This sheet comes in a heatguard grey colour, which looks nice on any building. You can customise the size to fit your project needs. Overall, these sheets are a smart choice for roofing.
These sheets could be used, for example, by a family to cover their patio and create a cosy outdoor area.
16mm heatguard triplewall polycarbonate cut to size
Visit this link to purchase glazing bars and accessories: https://livsupplies.co.uk/product-category/glazing-bars/
PST_16_3W_EG_27 – Product Guide
https://www.acrylics-online.co.uk/product-category/clear-acrylic-perspex/
| Size | Width, Length |
|---|
You may also like…
Brown Aluminium F Section
PVC End Sheet Closures
White Aluminium F Section
Brown Timber Support Glazing Bars
Fitting & Usage – Exitex Capex Snap Down Glazing Bar
Quick Installation Guide
(General guide – not full fitting instructions)
-
Cut to Length – Trim Base Bar and Top Capping to match the polycarbonate sheet.
-
Fit Gaskets – Insert EPDM rubber gaskets along each side of the Base Bar.
-
Pre-Drill & Fix – Drill fixing holes max 500mm apart (within 100mm of ends) and screw Base Bar to rafters with 5mm wood screws.
-
Prepare Sheets – Remove protective film from sheet edges.
-
Snap on Top Capping – Push legs into the Base Bar up-stand to form a tight seal.
-
Seal Ends – Apply silicone under end closure and End Cap top lip, then fit firmly.
Tips:
-
Allow 50mm sheet overhang into gutter.
-
Deduct 21mm from rafter centres for expansion.
-
Use fixing buttons for large or exposed areas.
-
Works best on roofs over 5° pitch.
Pack of 10 Fixing Buttons
